Dirt King Tahoe/Yukon Ball Joint Upper Control Arms

$749.00

2007-2020 Overview

 Description

The Dirt King ball joint upper control arms are engineered to improve suspension geometry, enabling additional front lift when paired with Dirt King shocks. Lifting a vehicle with stock upper control arms compromises both the geometry and structural strength due to excessive articulation at the factory joints. The Dirt King arms address these issues with improved caster settings for enhanced handling and re-engineered pivot angles for increased articulation. The inner pivots feature Probearing SilentSpin Hybrid bushings, offering the ideal combination of a free-spinning inner sleeve, typical of poly bushings, with the maintenance-free and greaseless advantages of OE elastomer bushings. Additionally, the standard ball joints have been upgraded to heavy-duty Moog ball joints ensuring superior durability. All components of these upper control arms are rebuildable or replaceable, promoting long-term durability and ease of maintenance. These arms arrive preassembled with detailed instructions for a straightforward installation.

Specifications

  • Amount of Lift: Allows for 0-3” of lift

  • Track Width: Stock

  • Maximum Backspacing: 4.75”

  • Minimum Rim Size: 16”

Wheel Travel / Lift
The Dirt King upper control arms must be paired with aftermarket coilover shocks to lift the vehicle. The Dirt King arms offer maximum down travel compared to the stock upper control arms. These arms are compatible with Dirt King, King, Fox, Bilstein, ADS, Icon, Eibach, and other various OEM replacement coilovers. Do not install these upper control arms with coil spacers paired with extended length aftermarket shocks.

What's Included

  • Chromoly upper control arms

  • Probearing SilentSpin Hybrid bushings

  • Moog ball joints

  • Ball joint caps

  • Dirt King sticker pack

  • Installation instructions

Features

  • CAD designed

  • Formed steel bushing gussets

  • Constructed with 4130 chromoly tubing

  • Preassembled for fast installation

  • Maintenance free bushings

  • Zinc plated components for corrosion resistance

  • Durable black powder coat

  • Professionally MIG welded

  • Proudly made in the USA

Compatibility

2007-2020 Chevy Tahoe 2WD / 4WD
2007-2020 GMC Yukon 2WD / 4WD


2021-2024 Overview

 Description

The Dirt King ball joint upper control arms are engineered to improve suspension geometry, enabling additional front lift when paired with Dirt King shocks. Lifting a vehicle with stock upper control arms compromises both the geometry and structural strength due to excessive articulation at the factory joints. The Dirt King arms address these issues with improved caster settings for enhanced handling and re-engineered pivot angles for increased articulation. The inner pivots feature Probearing SilentSpin bushings, offering the ideal combination of a free-spinning inner sleeve, typical of poly bushings, with the maintenance-free and greaseless advantages of OE elastomer bushings. Additionally, the standard ball joints have been upgraded to heavy-duty Moog ball joints ensuring superior durability. All components of these upper control arms are rebuildable or replaceable, promoting long-term durability and ease of maintenance. These arms arrive preassembled with detailed instructions for a straightforward installation.

Specifications

  • Amount of Lift: Allows for 0-3.5” of lift

  • Track Width: Stock

  • Maximum Backspacing: 4.75”

  • Minimum Rim Size: 17”

Wheel Travel / Lift
The Dirt King upper control arms must be paired with aftermarket coilover shocks to lift the vehicle. The Dirt King arms offer maximum down travel compared to the stock upper control arms. These arms are compatible with Dirt King, King, Fox, Bilstein, ADS, Icon, Eibach, and other various OEM replacement coilovers. Do not install these upper control arms with coil spacers paired with extended length aftermarket shocks.

What's Included

  • Chromoly upper control arms

  • Probearing SilentSpin bushings

  • Moog ball joints

  • Ball joint caps

  • Dirt King sticker pack

  • Installation instructions

Features

  • CAD designed

  • Formed steel bushing gussets

  • Constructed with 4130 chromoly tubing

  • Preassembled for fast installation

  • Maintenance free bushings

  • Zinc plated components for corrosion resistance

  • Durable black powder coat

  • Professionally MIG welded

  • Proudly made in the USA

Compatibility

2021-2024 Chevy Tahoe 2WD / 4WD
2021-2024 GMC Yukon 2WD / 4WD

Year:
OEM Suspension Type for 07-20:

2007-2020 Overview

 Description

The Dirt King ball joint upper control arms are engineered to improve suspension geometry, enabling additional front lift when paired with Dirt King shocks. Lifting a vehicle with stock upper control arms compromises both the geometry and structural strength due to excessive articulation at the factory joints. The Dirt King arms address these issues with improved caster settings for enhanced handling and re-engineered pivot angles for increased articulation. The inner pivots feature Probearing SilentSpin Hybrid bushings, offering the ideal combination of a free-spinning inner sleeve, typical of poly bushings, with the maintenance-free and greaseless advantages of OE elastomer bushings. Additionally, the standard ball joints have been upgraded to heavy-duty Moog ball joints ensuring superior durability. All components of these upper control arms are rebuildable or replaceable, promoting long-term durability and ease of maintenance. These arms arrive preassembled with detailed instructions for a straightforward installation.

Specifications

  • Amount of Lift: Allows for 0-3” of lift

  • Track Width: Stock

  • Maximum Backspacing: 4.75”

  • Minimum Rim Size: 16”

Wheel Travel / Lift
The Dirt King upper control arms must be paired with aftermarket coilover shocks to lift the vehicle. The Dirt King arms offer maximum down travel compared to the stock upper control arms. These arms are compatible with Dirt King, King, Fox, Bilstein, ADS, Icon, Eibach, and other various OEM replacement coilovers. Do not install these upper control arms with coil spacers paired with extended length aftermarket shocks.

What's Included

  • Chromoly upper control arms

  • Probearing SilentSpin Hybrid bushings

  • Moog ball joints

  • Ball joint caps

  • Dirt King sticker pack

  • Installation instructions

Features

  • CAD designed

  • Formed steel bushing gussets

  • Constructed with 4130 chromoly tubing

  • Preassembled for fast installation

  • Maintenance free bushings

  • Zinc plated components for corrosion resistance

  • Durable black powder coat

  • Professionally MIG welded

  • Proudly made in the USA

Compatibility

2007-2020 Chevy Tahoe 2WD / 4WD
2007-2020 GMC Yukon 2WD / 4WD


2021-2024 Overview

 Description

The Dirt King ball joint upper control arms are engineered to improve suspension geometry, enabling additional front lift when paired with Dirt King shocks. Lifting a vehicle with stock upper control arms compromises both the geometry and structural strength due to excessive articulation at the factory joints. The Dirt King arms address these issues with improved caster settings for enhanced handling and re-engineered pivot angles for increased articulation. The inner pivots feature Probearing SilentSpin bushings, offering the ideal combination of a free-spinning inner sleeve, typical of poly bushings, with the maintenance-free and greaseless advantages of OE elastomer bushings. Additionally, the standard ball joints have been upgraded to heavy-duty Moog ball joints ensuring superior durability. All components of these upper control arms are rebuildable or replaceable, promoting long-term durability and ease of maintenance. These arms arrive preassembled with detailed instructions for a straightforward installation.

Specifications

  • Amount of Lift: Allows for 0-3.5” of lift

  • Track Width: Stock

  • Maximum Backspacing: 4.75”

  • Minimum Rim Size: 17”

Wheel Travel / Lift
The Dirt King upper control arms must be paired with aftermarket coilover shocks to lift the vehicle. The Dirt King arms offer maximum down travel compared to the stock upper control arms. These arms are compatible with Dirt King, King, Fox, Bilstein, ADS, Icon, Eibach, and other various OEM replacement coilovers. Do not install these upper control arms with coil spacers paired with extended length aftermarket shocks.

What's Included

  • Chromoly upper control arms

  • Probearing SilentSpin bushings

  • Moog ball joints

  • Ball joint caps

  • Dirt King sticker pack

  • Installation instructions

Features

  • CAD designed

  • Formed steel bushing gussets

  • Constructed with 4130 chromoly tubing

  • Preassembled for fast installation

  • Maintenance free bushings

  • Zinc plated components for corrosion resistance

  • Durable black powder coat

  • Professionally MIG welded

  • Proudly made in the USA

Compatibility

2021-2024 Chevy Tahoe 2WD / 4WD
2021-2024 GMC Yukon 2WD / 4WD

Disclaimer

All products sold or manufactured by Dirt King are intended for off-road use only. Our products are strictly engineered and tested and are not to be modified from their original design in any way. Welding should always be done at a qualified and certified facility only. Customer assumes all liability in assuring that parts are installed correctly, maintained, and not modified or altered in any way. Dirt King is not responsible or liable for any accidents, injuries, or deaths that may occur from the use of any products offered. Suspension modifications may change the dynamics and stability characteristics of the vehicle. Ensuring prompt wheel alignment and ADAS recalibration after suspension modifications is critical and the sole responsibility of the customer.
